Stealth Tahoe

RadExpand 5 Plus (Slate Blue)

$1,899.00
$1,899.00
Out Of Stock
Product Data
SKU:
103-00056
UPC/EAN:
Description

Electric Folding Bike

RadExpand 5 Plus

Rad's taken the classic RadExpand and enhanced it with front suspension and hydraulic disc brakes for smoother rides on any terrain. Our most advanced folding bike yet features our turn signals, all-new tech, and retractable pedals for even easier storage.

For riders 4'10"-5'10"

Electronics

  • Battery

    15Ah 720 Wh 15Ah Safe Shield Advanced External Battery, Samsung 50GB or LG M50LT cells, UL Certified to UL-2271

  • Charger

    48VDC, 2 Amp Rad Power Bikes smart charger, operates on 100V-240V AC power outlets

  • Class

    Class switchable between 1 and 2. Ships in Class 2 status.

  • Display

    Rad custom color display. See Display section below for details.

  • Hub Motor

    Rear hub 750W, 64 Nm torque
    Stated wattage is the manufacturer’s rated power capacity. Actual power-to-ground wattage is under 750W to ensure ebike regulatory compliance and may vary depending on riding conditions.

  • Lights

    Auto-on feature
    Front: ~200 lumens LED headlight with built-in reflector
    Rear: Integrated taillight with brake light and turn signals

  • Pedal Assist

    Torque sensor, 5 PAS Levels, plus a zero assist option

  • Range

    Estimated 20-60 miles per charge

  • Throttle

    Half twist throttle

  • USB Ports

    One USB-C port, located on display

Components

  • Bell

    Yes

  • Brake System

    Hydraulic Disc, Gemma GA-1000B

  • Brake Pads

    Gemma Semi-Metallic G2

  • Brake Rotors

    180mm x 2.3mm

  • Crank Set

    48T with dual sided chain ring cover, 170mm crank arms

  • Derailleur

    7 speed Shimano

  • Fenders

    Full coverage front and rear fenders

  • Fork

    Exsho STRONG-C hydraulic suspension fork, 50mm travel, bolt-on axle

  • Frame

    Aluminum

  • Freewheel/Cassette

    7-speed freewheel, 14-32T

  • Gearing

    1x7 speed

  • Grips

    Ergonomic rubber comfort grips

  • Handlebar

    Aluminum, 680 mm wide

  • Kickstand

    Side mounted, adjustable angle kickstand

  • Pedals

    Composite platform, CrMo axle with reflectors, standard 9/16" x 20 TPI threading, folding

  • Rear Rack

    Integrated, 59 lb (27 kg) carrying capacity

  • Saddle

    Padded flat touring saddle with shallow anatomic cut-out, wide contoured sides

  • Seatpost

    390 mm x 27.2 mm

  • Seatpost Clamp

    31.8 mm

  • Shifter

    Shimano 7-speed thumb shifter

  • Stem

    Folding stem raiser with 45mm A-Head stem

  • Tires

    CST BFT 20" x 4.0", e-bike rated with puncture-resistant liner and reflective strip
